Wire ladder, 200 mm

C4

E No:

|

MP-number: 723Z4

Wire mesh tray for flexible installations. The diameter of the wires is 5 mm. The wire mesh tray is made of a zinc-magnesium alloy (25 µm) and is suitable for environmental class max C4. The advantage of this material is that it self-heals, for example when cut, and is a more durable alternative to traditional hot-dip galvanising. Several of the accessories are shared with the rest of the MP range. Can be ordered in any painted colour.
All variants

Product details

  • MP-number 723Z4
  • EAN 7394333051383
  • Length 2500 mm
  • Width 200 mm
  • Height 58 mm
  • Weight 4.2 kg
  • Climate impact 11.34 kgCO2e
  • Surface treatment Z4
  • Corrosion class C4
  • Wire diameter 5 mm

Documents

Certifications

Comments on the product

Do you have any comments on the product? Please contact us if you have any feedback on this product. Use the link to access our product feedback form.

Variants

MP-number

E No

Wire diameter

Width

Color

Surface treatment

Corrosion class

719E

4 mm

55 mm

Electrogalvanized 10 µm

C1

Select

MP-number

E No

Wire diameter

Width

Color

Surface treatment

Corrosion class

720E

4 mm

75 mm

Electrogalvanized 10 µm

C1

Select

MP-number

E No

Wire diameter

Width

Color

Surface treatment

Corrosion class

722E

5 mm

120 mm

Electrogalvanized 10 µm

C1

Select

MP-number

E No

Wire diameter

Width

Color

Surface treatment

Corrosion class

723E

5 mm

200 mm

Electrogalvanized 10 µm

C1

Select

MP-number

E No

Wire diameter

Width

Color

Surface treatment

Corrosion class

724E

5 mm

300 mm

Electrogalvanized 10 µm

C1

Select

MP-number

E No

Wire diameter

Width

Color

Surface treatment

Corrosion class

725E

6 mm

400 mm

Electrogalvanized 10 µm

C1

Select

MP-number

E No

Wire diameter

Width

Color

Surface treatment

Corrosion class

726E

6 mm

500 mm

Electrogalvanized 10 µm

C1

Select

MP-number

E No

Wire diameter

Width

Color

Surface treatment

Corrosion class

727E

6 mm

600 mm

Electrogalvanized 10 µm

C1

Select

MP-number

E No

Wire diameter

Width

Color

Surface treatment

Corrosion class

719V

4 mm

55 mm

NCS S 0500-N (white)

Lacquered

C2

Select

MP-number

E No

Wire diameter

Width

Color

Surface treatment

Corrosion class

720V

4 mm

75 mm

NCS S 0500-N (white)

Lacquered

C2

Select

MP-number

E No

Wire diameter

Width

Color

Surface treatment

Corrosion class

722V

5 mm

120 mm

NCS S 0500-N (white)

Lacquered

C2

Select

MP-number

E No

Wire diameter

Width

Color

Surface treatment

Corrosion class

723V

5 mm

200 mm

NCS S 0500-N (white)

Lacquered

C2

Select

MP-number

E No

Wire diameter

Width

Color

Surface treatment

Corrosion class

724V

5 mm

300 mm

NCS S 0500-N (white)

Lacquered

C2

Select

MP-number

E No

Wire diameter

Width

Color

Surface treatment

Corrosion class

725V

6 mm

400 mm

NCS S 0500-N (white)

Lacquered

C2

Select

MP-number

E No

Wire diameter

Width

Color

Surface treatment

Corrosion class

726V

6 mm

500 mm

NCS S 0500-N (white)

Lacquered

C2

Select

MP-number

E No

Wire diameter

Width

Color

Surface treatment

Corrosion class

727V

6 mm

600 mm

NCS S 0500-N (white)

Lacquered

C2

Select

MP-number

E No

Wire diameter

Width

Color

Surface treatment

Corrosion class

719R

4 mm

55 mm

Stainless steel 316L

C5-M

Select

MP-number

E No

Wire diameter

Width

Color

Surface treatment

Corrosion class

720R

4 mm

75 mm

Stainless steel 316L

C5-M

Select

MP-number

E No

Wire diameter

Width

Color

Surface treatment

Corrosion class

722R

5 mm

120 mm

Stainless steel 316L

C5-M

Select

MP-number

E No

Wire diameter

Width

Color

Surface treatment

Corrosion class

723R

5 mm

200 mm

Stainless steel 316L

C5-M

Select

MP-number

E No

Wire diameter

Width

Color

Surface treatment

Corrosion class

724R

5 mm

300 mm

Stainless steel 316L

C5-M

Select

MP-number

E No

Wire diameter

Width

Color

Surface treatment

Corrosion class

725R

6 mm

400 mm

Stainless steel 316L

C5-M

Select

MP-number

E No

Wire diameter

Width

Color

Surface treatment

Corrosion class

726R

6 mm

500 mm

Stainless steel 316L

C5-M

Select

MP-number

E No

Wire diameter

Width

Color

Surface treatment

Corrosion class

727R

6 mm

600 mm

Stainless steel 316L

C5-M

Select

MP-number

E No

Wire diameter

Width

Color

Surface treatment

Corrosion class

719Z4

4 mm

55 mm

Z4

C4

Select

MP-number

E No

Wire diameter

Width

Color

Surface treatment

Corrosion class

720Z4

4 mm

75 mm

Z4

C4

Select

MP-number

E No

Wire diameter

Width

Color

Surface treatment

Corrosion class

722Z4

5 mm

120 mm

Z4

C4

Select

MP-number

E No

Wire diameter

Width

Color

Surface treatment

Corrosion class

723Z4

5 mm

200 mm

Z4

C4

Selected

MP-number

E No

Wire diameter

Width

Color

Surface treatment

Corrosion class

724Z4

5 mm

300 mm

Z4

C4

Select

MP-number

E No

Wire diameter

Width

Color

Surface treatment

Corrosion class

725Z4

6 mm

400 mm

Z4

C4

Select

MP-number

E No

Wire diameter

Width

Color

Surface treatment

Corrosion class

726Z4

6 mm

500 mm

Z4

C4

Select

MP-number

E No

Wire diameter

Width

Color

Surface treatment

Corrosion class

727Z4

6 mm

600 mm

Z4

C4

Select
