Cable ladder MP-TS, 6 m, 300 mm

E No:

MP-number: 153S

Industrial ladder with thicker sheet metal and higher load-bearing capacity. The cable ladder is made of Sendzimir galvanised sheet (20 µm), suitable for environmental class max C2. This model features flat closed-rung steps with a centre-to-centre distance of 250 mm. The perforated sides allow branches, angle brackets, etc. to be fitted. Furthermore, the side profile shape allows the use of cables up to 19 mm in diameter over 98% of the width of the ladder. Ultimate failure load: more than or equal to 1.7 times the maximum load.

All variants All variants

Product details

MP-number 153S
EAN 7394333001289
Length 6000 mm
Width 300 mm
Height 56 mm
Weight 14.14 kg
Material thickness ladder side 1.25 mm
Climate impact 38.037 kgCO2e
Surface treatment Pre-galvanized 20 µm
Corrosion class C2
Cable ladder properties Closed rungs, Heavier loads
Model MP-TS

Documents

Environmental data galvanized S_en-GB.pdf

Certifications

Comments on the product

Do you have any comments on the product? Please contact us if you have any feedback on this product. Use the link to access our product feedback form.

Variants

MP-number	Length	Width	Corrosion class	Surface treatment
152S	6000 mm	200 mm	C2	Pre-galvanized 20 µm	Select
153S	6000 mm	300 mm	C2	Pre-galvanized 20 µm	Selected
154S	6000 mm	400 mm	C2	Pre-galvanized 20 µm	Select
155S	6000 mm	500 mm	C2	Pre-galvanized 20 µm	Select
156S	6000 mm	600 mm	C2	Pre-galvanized 20 µm	Select
