Cable ladder MP-SR, 3 m, 200 mm

C2

E No:

|

MP-number: 102SR

Cable ladder made of recycled Sendzimir galvanized (20 µm) sheet steel suitable for environmental class max C2. The material is 78.7% recycled consumer-based scrap and is produced using only fossil-free energy sources. The pins are perforated for easy cable attachment, pin spacing: c-c 250 mm. The second pin at each end is closed. The perforated side allows for the installation of branches, angle brackets, etc. In addition, the shape of the side profile allows cables up to 19 mm in diameter to utilize over 98% of the ladder width. Breaking load: greater than or equal to 1.7 times the maximum load.
All variants

Product details

  • MP-number 102SR
  • EAN 7394333000701
  • Length 3000 mm
  • Width 200 mm
  • Height 56 mm
  • Weight 5.17 kg
  • Material thickness ladder side 1 mm
  • Climate impact 4.498 kgCO2e
  • Surface treatment Pre-galvanized 20 µm
  • Corrosion class C2
  • Reduced Yes
  • Cable ladder properties Perforated rungs, Recycled material
  • Model MP-SR

Documents

Certifications

Comments on the product

Do you have any comments on the product? Please contact us if you have any feedback on this product. Use the link to access our product feedback form.

Variants

MP-number

E No

Length

Width

Corrosion class

Surface treatment

Reduced

102SR

3000 mm

200 mm

C2

Pre-galvanized 20 µm

Yes

Selected

MP-number

E No

Length

Width

Corrosion class

Surface treatment

Reduced

103SR

3000 mm

300 mm

C2

Pre-galvanized 20 µm

Yes

Select

MP-number

E No

Length

Width

Corrosion class

Surface treatment

Reduced

104SR

3000 mm

400 mm

C2

Pre-galvanized 20 µm

Yes

Select

MP-number

E No

Length

Width

Corrosion class

Surface treatment

Reduced

105SR

3000 mm

500 mm

C2

Pre-galvanized 20 µm

Yes

Select

MP-number

E No

Length

Width

Corrosion class

Surface treatment

Reduced

106SR

3000 mm

600 mm

C2

Pre-galvanized 20 µm

Yes

Select
