Wire ladder high, 200 mm

C1

E No:

|

MP-number: 723HE

Wire mesh tray for flexible installations. The diameter of the wires is 5 mm. A taller variant with 110 mm high sides, for when a little more space is required. The accessories are the same as for the lower model. The wire mesh tray is made of galvanised steel (10 µm) and is suitable for environmental class max C1. Several of the accessories are shared with the rest of the MP range. Can be ordered in any painted colour.
All variants

Product details

  • MP-number 723HE
  • EAN 7394333051246
  • Length 2500 mm
  • Width 200 mm
  • Height 109 mm
  • Weight 5 kg
  • Climate impact 13.55 kgCO2e
  • Surface treatment Electrogalvanized 10 µm
  • Corrosion class C1
  • Wire diameter 5 mm

Documents

Certifications

Comments on the product

Do you have any comments on the product? Please contact us if you have any feedback on this product. Use the link to access our product feedback form.

Variants

MP-number

E No

Wire diameter

Width

Surface treatment

Corrosion class

722HE

5 mm

120 mm

Electrogalvanized 10 µm

C1

Select

MP-number

E No

Wire diameter

Width

Surface treatment

Corrosion class

723HE

5 mm

200 mm

Electrogalvanized 10 µm

C1

Selected

MP-number

E No

Wire diameter

Width

Surface treatment

Corrosion class

724HE

5 mm

300 mm

Electrogalvanized 10 µm

C1

Select

MP-number

E No

Wire diameter

Width

Surface treatment

Corrosion class

725HE

6 mm

400 mm

Electrogalvanized 10 µm

C1

Select

MP-number

E No

Wire diameter

Width

Surface treatment

Corrosion class

726HE

6 mm

500 mm

Electrogalvanized 10 µm

C1

Select

MP-number

E No

Wire diameter

Width

Surface treatment

Corrosion class

727HE

6 mm

600 mm

Electrogalvanized 10 µm

C1

Select

MP-number

E No

Wire diameter

Width

Surface treatment

Corrosion class

722HR

5 mm

120 mm

Stainless steel 316L

C5-M

Select

MP-number

E No

Wire diameter

Width

Surface treatment

Corrosion class

723HR

5 mm

200 mm

Stainless steel 316L

C5-M

Select

MP-number

E No

Wire diameter

Width

Surface treatment

Corrosion class

724HR

5 mm

300 mm

Stainless steel 316L

C5-M

Select

MP-number

E No

Wire diameter

Width

Surface treatment

Corrosion class

725HR

6 mm

400 mm

Stainless steel 316L

C5-M

Select

MP-number

E No

Wire diameter

Width

Surface treatment

Corrosion class

726HR

6 mm

500 mm

Stainless steel 316L

C5-M

Select

MP-number

E No

Wire diameter

Width

Surface treatment

Corrosion class

727HR

6 mm

600 mm

Stainless steel 316L

C5-M

Select

MP-number

E No

Wire diameter

Width

Surface treatment

Corrosion class

722HZ4

5 mm

120 mm

Z4

C4

Select

MP-number

E No

Wire diameter

Width

Surface treatment

Corrosion class

723HZ4

5 mm

200 mm

Z4

C4

Select

MP-number

E No

Wire diameter

Width

Surface treatment

Corrosion class

724HZ4

5 mm

300 mm

Z4

C4

Select

MP-number

E No

Wire diameter

Width

Surface treatment

Corrosion class

725HZ4

6 mm

400 mm

Z4

C4

Select

MP-number

E No

Wire diameter

Width

Surface treatment

Corrosion class

726HZ4

6 mm

500 mm

Z4

C4

Select

MP-number

E No

Wire diameter

Width

Surface treatment

Corrosion class

727HZ4

6 mm

600 mm

Z4

C4

Select
