Floor stand 19"

E No:

MP-number: 849V

Floor rack with 540 mm wall spacer - white finish. MP-19" rack is a mounting kit that has two standards in the same rack data on one side, according to SS SS-EN 60297-3-100 with holes for cage nuts M6. Telecom on the other side, according to g:a SEN R 430115, with holes 6.5x31.75 mm for M6 screws. The height is 50 Units (44,45 mm) of which 48 are usable.

All variants All variants

Product details

MP-number 849V
EAN 7394333171951
Length 540 mm
Width 492 mm
Height 2223 mm
Weight 5.9 kg
Climate impact 15.163 kgCO2e
Surface treatment Lacquered
Color NCS S 0500-N (white)
Units 50 U
Suitable for 19" rack

Documents

Environmental data varnished_en-GB.pdf

Certifications

Comments on the product

Do you have any comments on the product? Please contact us if you have any feedback on this product. Use the link to access our product feedback form.

Variants

MP-number	Color	Length	Width
847E		270 mm	492 mm	Select
848E		350 mm	492 mm	Select
849E		540 mm	492 mm	Select
852E		600 mm	492 mm	Select
847V	NCS S 0500-N (white)	270 mm	492 mm	Select
848V	NCS S 0500-N (white)	350 mm	492 mm	Select
849V	NCS S 0500-N (white)	540 mm	492 mm	Selected
852V	NCS S 0500-N (white)	2330 mm	105 mm	Select
