Floor stand 19"

E No:

MP-number: 848E

Floor rack with 350 mm wall spacer - electro galvanized. MP-19" rack is a mounting kit that has two standards in the same rack data on one side, according to SS-EN 60297-3-100 with holes for cage nuts M6. Telecom on the other side, according to g:a SEN R 430115, with holes 6.5x31.75 mm for M6 screws. The height is 50 Units (44,45 mm) of which 48 are usable.

All variants All variants

Product details

MP-number 848E
EAN 7394333170695
Width 492 mm
Height 2223 mm
Depth 350 mm
Weight 5.6 kg
Climate impact per unit 15.008 kgCO2e
Surface treatment Electrogalvanized 10 µm
Units 50 U
Suitable for 19" rack

Documents

Environmental data Electro-galvanized E_en-GB.pdf

Certifications

Comments on the product

Do you have any comments on the product? Please contact us if you have any feedback on this product. Use the link to access our product feedback form.

Variants

MP-number	Color	Width	Height	Depth	Units
847E		492 mm	2223 mm	270 mm	50 U	Select
847V	NCS S 0500-N (white)	492 mm	2223 mm	270 mm	50 U	Select
848E		492 mm	2223 mm	350 mm	50 U	Selected
848V	NCS S 0500-N (white)	492 mm	2223 mm	350 mm	50 U	Select
849E		492 mm	2223 mm	540 mm	50 U	Select
849V	NCS S 0500-N (white)	492 mm	2223 mm	540 mm	50 U	Select
852E		492 mm	2223 mm	350–600 mm	50 U	Select
852V	NCS S 0500-N (white)	492 mm	2223 mm	350–600 mm	50 U	Select
