Cable tray – perforated, 600 mm

C2

E No:

|

MP-number: 3831V

Perforated tray with about 13% perforation - white. Painted trays are supplied with paint-free ends (internally). Other lengths and colours quoted on request. Bracket distance is determined by the length of the rail. 2 m rail = C-C 2 m and 3 m rail C-C = 3 m. 6 m rail needs a suspension in the middle. These values apply at normal load.
All variants

Product details

  • MP-number 3831V
  • EAN 7394333106984
  • Length 2000 mm
  • Width 600 mm
  • Height 45 mm
  • Weight 14.62 kg
  • Climate impact 39.035 kgCO2e
  • Surface treatment Lacquered
  • Color NCS S 0500-N (white)
  • Corrosion class C2
  • Configuration Perforated gutter

Documents

Certifications

Comments on the product

Do you have any comments on the product? Please contact us if you have any feedback on this product. Use the link to access our product feedback form.

Variants

MP-number

E No

Length

Width

Corrosion class

Surface treatment

Color

3931S

3000 mm

50 mm

C2

Pre-galvanized 20 µm

Select

MP-number

E No

Length

Width

Corrosion class

Surface treatment

Color

3931V

3000 mm

50 mm

C2

Lacquered

NCS S 0500-N (white)

Select

MP-number

E No

Length

Width

Corrosion class

Surface treatment

Color

3131S

3000 mm

75 mm

C2

Pre-galvanized 20 µm

Select

MP-number

E No

Length

Width

Corrosion class

Surface treatment

Color

3131V

3000 mm

75 mm

C2

Lacquered

NCS S 0500-N (white)

Select

MP-number

E No

Length

Width

Corrosion class

Surface treatment

Color

3231S

3000 mm

100 mm

C2

Pre-galvanized 20 µm

Select

MP-number

E No

Length

Width

Corrosion class

Surface treatment

Color

3231V

3000 mm

100 mm

C2

Lacquered

NCS S 0500-N (white)

Select

MP-number

E No

Length

Width

Corrosion class

Surface treatment

Color

3331S

3000 mm

150 mm

C2

Pre-galvanized 20 µm

Select

MP-number

E No

Length

Width

Corrosion class

Surface treatment

Color

3331V

3000 mm

150 mm

C2

Lacquered

NCS S 0500-N (white)

Select

MP-number

E No

Length

Width

Corrosion class

Surface treatment

Color

3431S

3000 mm

200 mm

C2

Pre-galvanized 20 µm

Select

MP-number

E No

Length

Width

Corrosion class

Surface treatment

Color

3431V

3000 mm

200 mm

C2

Lacquered

NCS S 0500-N (white)

Select

MP-number

E No

Length

Width

Corrosion class

Surface treatment

Color

3531S

2000 mm

300 mm

C2

Pre-galvanized 20 µm

Select

MP-number

E No

Length

Width

Corrosion class

Surface treatment

Color

3531V

2000 mm

300 mm

C2

Lacquered

NCS S 0500-N (white)

Select

MP-number

E No

Length

Width

Corrosion class

Surface treatment

Color

3631S

2000 mm

400 mm

C2

Pre-galvanized 20 µm

Select

MP-number

E No

Length

Width

Corrosion class

Surface treatment

Color

3631V

2000 mm

400 mm

C2

Lacquered

NCS S 0500-N (white)

Select

MP-number

E No

Length

Width

Corrosion class

Surface treatment

Color

3731S

2000 mm

500 mm

C2

Pre-galvanized 20 µm

Select

MP-number

E No

Length

Width

Corrosion class

Surface treatment

Color

3731V

2000 mm

500 mm

C2

Lacquered

NCS S 0500-N (white)

Select

MP-number

E No

Length

Width

Corrosion class

Surface treatment

Color

3831S

2000 mm

600 mm

C2

Pre-galvanized 20 µm

Select

MP-number

E No

Length

Width

Corrosion class

Surface treatment

Color

3831V

2000 mm

600 mm

C2

Lacquered

NCS S 0500-N (white)

Selected
