Cable ladder MP-RFF, 6 m RF, 200 mm

C5-I

E No:

|

MP-number: 6012-33

This robust and stainless steel ladder is customized to withstand the challenging conditions found along coastlines and offshore areas with high salt levels. Its impressive 6-meter length is engineered to manage console distances throughout its span. The ladder is equipped with perforated rungs spaced at 300 mm intervals while meeting the requirements of the most demanding environmental Class, C5-I.
All variants

Product details

  • MP-number 6012-33
  • EAN 7394333400136
  • Length 6100 mm
  • Width 200 mm
  • Height 157 mm
  • Weight 22.02 kg
  • Material thickness ladder side 1 mm
  • Climate impact 105.696 kgCO2e
  • Surface treatment Stainless steel 304
  • Corrosion class C5-I
  • Cable ladder properties Perforated rungs, Heavier loads, Cantilever, Tube Profile
  • Model MP-RFF

Documents

Certifications

Comments on the product

Do you have any comments on the product? Please contact us if you have any feedback on this product. Use the link to access our product feedback form.

Variants

MP-number

E No

Length

Width

6012-33

6100 mm

200 mm

Selected

MP-number

E No

Length

Width

6013-33

6100 mm

300 mm

Select

MP-number

E No

Length

Width

6014-33

6100 mm

400 mm

Select

MP-number

E No

Length

Width

6015-33

6100 mm

500 mm

Select

MP-number

E No

Length

Width

6016-33

6100 mm

600 mm

Select
