Cable ladder MP-FZ, 6 m, 600 mm

E No:

MP-number: 196Z

An extra reinforced cable ladder for really tough environments, such as heavy process industry. Also used for long console distances - up to 6 m. The cable ladder is 6 m long, hot-dip galvanized (55 µm) and used in environmental class max C4. The construction of the cable ladder allows the use of cables over the entire width up to 40 mm cable diameter. Rung distance: c-c 300 mm. Ultimate failure load: more than or equal to 1.7 times the maximum load.

All variants All variants

Product details

MP-number 196Z
EAN 7394333003481
Length 6000 mm
Width 600 mm
Height 100 mm
Weight 40.2 kg
Material thickness ladder side 2.5 mm
Climate impact 113.766 kgCO2e
Surface treatment Hot-dip galvanized 55 µm
Corrosion class C4
Cable ladder properties Perforated rungs, Heavier loads, Cantilever
Model MP-FZ

Documents

Environmental data galvanized Z_en-GB.pdf

Certifications

Comments on the product

Do you have any comments on the product? Please contact us if you have any feedback on this product. Use the link to access our product feedback form.

Variants

MP-number	Length	Width	Corrosion class	Surface treatment
192Z	6000 mm	200 mm	C4	Hot-dip galvanized 55 µm	Select
193Z	6000 mm	300 mm	C4	Hot-dip galvanized 55 µm	Select
194Z	6000 mm	400 mm	C4	Hot-dip galvanized 55 µm	Select
195Z	6000 mm	500 mm	C4	Hot-dip galvanized 55 µm	Select
196Z	6000 mm	600 mm	C4	Hot-dip galvanized 55 µm	Selected
