Corners TBC, 65x135 mm

E No:

|

MP-number: TBC135-3

Corner - white finish aluminium/plastic, acts as both inner and outer corners and also permits a few degrees of deviation from a 90° angle. Suitable for: TB 1310, 1340.

All variants All variants

Product details

MP-number TBC135-3
EAN 7394333402260
Length 90 mm
Width 90 mm
Height 135 mm
Weight 0.17 kg
Surface treatment Painted aluminum
Color RAL 9010 (white)
Suitable for Window sill channels

Documents

Env data Channels Alu and varnish_en-GB.pdf

Comments on the product

Do you have any comments on the product? Please contact us if you have any feedback on this product. Use the link to access our product feedback form.

Variants

	MP-number	E No	Length	Width	Height	Color	Surface treatment	Suitable for
	TBC100-1		90 mm	90 mm	100 mm	Natural anodized	Anodized	Window sill channels	Select
	TBC135-1		90 mm	90 mm	135 mm	Natural anodized	Anodized	Window sill channels	Select
	TBC170-1		90 mm	90 mm	170 mm	Natural anodized	Anodized	Window sill channels	Select
	TBC220-1		90 mm	90 mm	220 mm	Natural anodized	Anodized	Window sill channels	Select
	TBC100-2		90 mm	90 mm	100 mm	RAL 9005 (black)	Painted aluminum	Window sill channels	Select
	TBC135-2		90 mm	90 mm	135 mm	RAL 9005 (black)	Painted aluminum	Window sill channels	Select
	TBC170-2		90 mm	90 mm	170 mm	RAL 9005 (black)	Painted aluminum	Window sill channels	Select
	TBC100-3		90 mm	90 mm	100 mm	RAL 9010 (white)	Painted aluminum	Window sill channels	Select
	TBC135-3		90 mm	90 mm	135 mm	RAL 9010 (white)	Painted aluminum	Window sill channels	Selected
	TBC170-3		90 mm	90 mm	170 mm	RAL 9010 (white)	Painted aluminum	Window sill channels	Select
	TBC220-3		90 mm	90 mm	220 mm	RAL 9010 (white)	Painted aluminum	Window sill channels	Select
