Cable ladder MP-Z4R, 6 m, 500 mm

E No:

MP-number: 155Z4R

Industrial ladder with high load-bearing capacity. Suitable for both indoor and outdoor installation. The material is 95,2% recycled consumer-based scrap and is produced using only fossil-free energy sources. Another significant advantage is that the material is self-healing, for example, when cut. The ladder is usable in environmental class max C4. This model has perforated rungs with distance of c-c 250 mm (the second and fourth rungs at each end are closed). The perforated side allows for the installation of branches and angle brackets. The shape of the sides allows cables up to 19 mm in diameter to utilize 98% of the ladder's width.

All variants All variants

Product details

MP-number 155Z4R
EAN 7394333047317
Length 6000 mm
Width 500 mm
Height 56 mm
Weight 16.1 kg
Material thickness ladder side 1.25 mm
Climate impact 18.515 kgCO2e
Surface treatment Z4
Corrosion class C4
Reduced Yes
Cable ladder properties Closed rungs, Heavier loads, Recycled material
Model MP-Z4R

Documents

Environmental data galvanized Z4_en-GB.pdf

Certifications

Comments on the product

Do you have any comments on the product? Please contact us if you have any feedback on this product. Use the link to access our product feedback form.

Variants

MP-number	Length	Width	Corrosion class	Surface treatment	Reduced
152Z4R	6000 mm	200 mm	C4	Z4	Yes	Select
153Z4R	6000 mm	300 mm	C4	Z4	Yes	Select
154Z4R	6000 mm	400 mm	C4	Z4	Yes	Select
155Z4R	6000 mm	500 mm	C4	Z4	Yes	Selected
156Z4R	6000 mm	600 mm	C4	Z4	Yes	Select
