Cable ladder MP-SFT, SF, 400 mm
C5-M
E No:
|
MP-number: 6004-48
This acid-resistant cable ladder is perfect for use along coastlines and offshore areas with high salt concentrations in the environment. At a length of 6 meters, the ladder is equipped with perforated rungs spaced 300 mm apart. It's designed to meet the requirements of environmental Class C5-M, making it suitable for environments demanding high resistance to corrosion and aggressive elements.
All variants
Product details
- MP-number 6004-48
- EAN 7394333400082
- Length 6000 mm
- Width 400 mm
- Height 55 mm
- Weight 16.26 kg
- Material thickness ladder side 1 mm
- Climate impact 74.308 kgCO2e
- Surface treatment Stainless steel 316L
- Corrosion class C5-M
- Cable ladder properties Perforated rungs, Tube Profile
- Model MP-RFT
Documents
Environmental data art 48_en-GB.pdf
Certifications
Comments on the product
Do you have any comments on the product? Please contact us if you have any feedback on this product. Use the link to access our product feedback form.
